Graziano SAG 12 Centre Lathe (12516)
Used Graziano SAG 12 Centre Lathe (12516)
800 b/c, swing Ø306, gap Ø440mm, bore Ø41, QCTP
SOLD
Centers height : 153mm
Between Centre: 800mm
Swing over bed: Ø306mm
Swing in gap bed: Ø440mm
Bed width: 245mm
Spindle Bore: Ø41mm
Spindle nose Cam-Lock : D4
Spindle speeds : 80 to 2600 rpm
2 ranges
Max tool section : 20 x 20mm
Metrical pitch Whitworth, Pitch and Module
Tailstock sleeve stroke : 145mm
Motor: 380V 50 Hz
Dimensions: 1920 x 860 x 1295mm
Weight: 1000 Kg
Quick Change Tool Post - Multifix with 1 holder
Ø200mm 3 Jaw chuck
Ø260mm 4 Jaw chuck
Revolving centre
Fixed steady
Very good condition!
